| Thread Diameter Size (TDZ) | M36 | Chamfer | 3 to 5 Threads |
| Thread Pitch (TP) | 4 mm | Coating | Uncoated |
| Thread Standard | Metric | Flute Type | Straight |
| Overall Length (OAL) | 6-1/16″ | End Shape | Chamfer |
| Thread Cutting Part Length (THL) | 3″ | Style | Plug |
| Flute Count (NOF) | 4 | Measurement Type | Metric |
| Cutting Edge Material | HSS | Series/List # | 7500 |
| Thread Tolerance Class (TCTR) | D9 | Thread Size | M36 × 4 |
| Tool Type | General Purpose Tap |
Product Features
| Remarks | Straight Flute hand taps are used for hand tapping and machine tapping in through holes or blind holes in a wide variety of materials. |
Country of Origin | USA |
Shipping Info
LocalField10
0
Package Length
6.30000
Package Width
2.00000
Package Height
1.80000
Package Weight
1.5
